Air Traps

These traps automatically discharge condensate that occurs in compressed air systems.
Miyawaki air and gas traps are products of more than 50 years of Miyawaki technology and results,
and they offer superb performance in a wide range of applications from general air compression systems to nuclear power plants.

Inverted Bucket Traps
  • Inverted Bucket Traps

    Inverted Bucket Traps
  • Operating characteristics: Insensible to dirt and scale, intermittent discharge of condensate.
    Advantages:
    - Easy maintenance (all units attached to cover, etc.)
    - Pressure-balancing lines are not necessary

Ball Float Traps
  • Ball Float Traps

    Ball Float Traps
  • Operating characteristics: Self-adjusts the degree of opening according to condensate volume for continuous discharge.
    Advantages: ■Excellent sealing performance
          ■Well-balanced condensate discharge
          ■Equipped as standard with one push blowdown valve (AG11, AG12)

Thermodynamic Disc Traps
  • Thermodynamic Disc Traps

    Thermodynamic Disc Traps
  • Operating characteristics: Can be installed vertically, intermittent discharge of condensate.
    Advantages: ■Also functions as bypass valve (reducing works costs and saving space)
          ■No pressure equalizer required
