Ball Float Traps
Air Traps Ball Float Traps
AG12
One push blow mechanism
Features/Applications
Features
Superb sealing and durability
Offers superb sealing and durability thanks to the MIYAWAKI SCCV System. This valve mechanism was developed by MIYAWAKI to increase valve durability and ensure maximum sealing performance.
Easy maintenance
All units are attached to the cover, making maintenance easy.
Manual lifting device
The manual lifting device comes standard with a push blowdown valve, designed to clear any blockages in the valve.
Typical applications
Suitable for air pipings, aftercoolers, receiver tanks, and other such applications.
Dimensions/Weight
Dimensions/Weight
| Size | Dimensions (mm) | Dimensions (in) | Weight | |||||||||||
| L | H1 | H2 | W1 | W2 | W3 | L | H1 | H2 | W1 | W2 | W3 | (kg) | (lb) | |
| 3/4” | 140 | 47 | 113 | 129 | 92 | 10 | 5.5 | 1.9 | 4.4 | 5.1 | 3.6 | 0.4 | 6,0 | 13.2 |
| 1” | ||||||||||||||
*Please contact MIYAWAKI for further information.
Specifications
| Model | Connection |
Max. operating pressure |
Max. operating pressure differential |
Max. operating temperature |
Body material | ||||
| Type | Size | (MPa) | (psig) | (MPa) | (psig) | (℃) | (℉) | ||
| AG12-9 |
Screwed Rc,NPT |
3/4” | 0,97 | 140.65 | 0,97 | 140.65 | 100 | 212 |
Cast iron FC250 |
|
1” |
|||||||||
*Screwed-flange and customized face-to-face dimensions on request.
*Please contact MIYAWAKI for further information.
Discharge Capacity
Installation Examples
■Related Products Models for reference
Y strainer YM1
Download
* Membership registration is required to download the documents.
