G Series | Ball Float Steam Traps

Steam Traps G Series | Ball Float Steam Traps GTH12

Steam Traps G Series | Ball Float Steam Traps

GTH12

  • SCCV System
  • Stainless Steel
  • Supports condensate recovery
  • Horizontal installation
  • Vertical installation
  • Bypass function
  • Auto blow-off
    • Option
      - Customized flange face-to-face
      - ASTM available

    Stainless steel OK

    Steam Traps G Series | Ball Float Steam Traps GTH12

    Features/Applications

    Features

    • No condensate logging on primary side (continuous discharge float system)

      The floating mechanism discharges condensate immediately at saturation temperature, preventing condensate logging on the primary side. Ideally installed in applications where condensate logging cannot be accepted.

    • Superb sealing and durability

      Offers superb sealing and durability thanks to its SCCV System.
      This is an original mechanism developed by MIYAWAKI to increase valve durability and ensuring maximum sealing performance. The body is designed to withstand even high pressure applications up to 50 barg.

    • Free from steam and air locking

      A quick start up is guaranteed, thanks to the installed air vent. The air vent discharges cold condensate and prevents air and steam locking.

    • Easy maintenance

      For quick and easy maintenance, all valve parts are attached to the cover, making maintenance easy. The trap can be serviced directly in line.

    • Condensate recovery

      With its high degree of back pressure tolerance, this model supports condensate recovery.


    *’SCCV System’ is an abbreviation of Self Closing and Centering Valve System.



    Typical applications

    The trap is typically applied to high temperature, medium-to-high pressure steam ducts and process equipments.

    Dimensions/Weight

    Dimensions/Weight

    Flanged




    Size Dimensions (mm) Dimensions (in) Weight (kg) Weight (lb)
    L H1 H2 W1 W2 L H1 H2 W1 W2 JIS(FF) JIS(RF) ASME/JPI(RF) JIS(FF) JIS(RF) ASME/JPI(RF)
    10K,16K,20K 30K,40K 150lb,300lb 600lb 10K,16K,20K 30K,40K 150lb,300lb 600lb
    1/2” 250 75 95 30 195 9.8 3.0 3.7 1.2 7.7 12,7 14,0 12,7 14,0 28 30.9 28 30.9
    3/4” 13,5 14,2 13,5 14,2 29.8 31.3 29.8 31.3
    1” 14,0 15,2 14,0 15,2 30.9 33.5 30.9 33.5
    Size Dimensions (mm) Dimensions (in) Weight (kg) Weight (lb)
    L H1 H2 W1 W2 L H1 H2 W1 W2 ASME/JPI DIN JIS (FF) JIS (RF) ASME/JPI DIN JIS (FF) JIS (RF)
    150lb,300lb 600lb PN40 10K,16K,20K 30K,40K 150lb,300lb 600lb PN40 10K,16K,20K 30K,40K
    1/2" 250 75 95 30 195 9.8 3.0 3.7 1.2 7.7 12,7 14,0   12,7 14,0 28 30.9   28 30.9
    3/4" 13,5 14,2   13,5 14,2 29.8 31.3   29.8 31.3
    1" 14,0 15,2   14,0 15,2 30.9 33.5   20.9 33.5

    *Available flange standards: ASME/JPI, DIN, JIS
    *Customized face-to-face dimensions on request.
    *Please contact MIYAWAKI for further information.





    Socket Weld




    Size Dimensions (mm) Dimensions (in) Weight
    L H1 H2 W1 W2 L H1 H2 W1 W2 (kg) (lb)
    1/2” 220 75 95 30 195 8.7 3.0 3.7 1.2 7.7 11,5 25.4
    3/4” 11,6 25.6
    1” 11,7 25.8

    Specifications

    Model Connection

    Max. operating

    pressure

    Max. operating differential

    pressure

    Max. operating

    temperature

    Body

    material

    Type Size PMO(MPa) PMO(psig) ⊿PMX(MPa) ⊿PMX(psig) TMO(℃) TMO(℉)
    GTH12-5F Flanged
    FF,RF
    1/2” 3,2 464 0,5 73 400 752



    Cast

    steel

    SCPH2

    3/4”
    1”
    GTH12-16F 1/2” 1,6 230
    3/4”
    1”
    GTH12-25F 1/2” 2,5 363
    3/4”
    1”
    GTH12-32F 1/2” 3,2 464
    3/4”
    1”
    GTH12-45F 1/2” 5,0 725 4,5 652 425 800
    3/4”
    1”
    GTH12-5W

    Socket Weld

    SW

    1/2” 3,2 464 0,5 73 400 752
    3/4”
    1”
    GTH12-16W 1/2” 1,6 230
    3/4”
    1”
    GTH12-25W 1/2” 2,5 363
    3/4”
    1”
    GTH12-32W 1/2” 3,2 464
    3/4”
    1”
    GTH12-45W 1/2” 5,0 725 4,5 652 425 800
    3/4”
    1”

    ●Maximum allowable pressure (PMA): 3,2MPa (464psig) (GTH12-45: 5,0MPa (725psig))
    ●Maximum allowable temperature (TMA): 400℃ (752℉)  (GTH12-45: 425℃ (800℉))

    ●Minimum operating differential pressure (⊿PMN): 0,01MPa (1.5psig) ⊿PMN is the minimum operating differential pressure between the trap inlet and outlet.
    ●Maximum operating back pressure (PMOB): 90% of inlet-side pressure


    *Available flange standards: ASME/JPI, DIN, JIS
    *Customized size 1-1/4”, 1-1/2”, and 2” on request.
    *ASTM material (WCB) and Stainless Steel (SCS13A) on request.

    *Vertical installation on request.
    *A version with the direction of the inlet and outlet reversed on request.

    *Please contact MIYAWAKI for further information.

    Discharge Capacity


    Installation Examples


    ■ Additional products for reference
    Y strainer: YM1
    Air vent: AT9N

    Features

    • No condensate logging on primary side (continuous discharge float system)

      The floating mechanism discharges condensate immediately at saturation temperature, preventing condensate logging on the primary side. Ideally installed in applications where condensate logging cannot be accepted.

    • Superb sealing and durability

      Offers superb sealing and durability thanks to its SCCV System.
      This is an original mechanism developed by MIYAWAKI to increase valve durability and ensuring maximum sealing performance. The body is designed to withstand even high pressure applications up to 50 barg.

    • Free from steam and air locking

      A quick start up is guaranteed, thanks to the installed air vent. The air vent discharges cold condensate and prevents air and steam locking.

    • Easy maintenance

      For quick and easy maintenance, all valve parts are attached to the cover, making maintenance easy. The trap can be serviced directly in line.

    • Condensate recovery

      With its high degree of back pressure tolerance, this model supports condensate recovery.


    *’SCCV System’ is an abbreviation of Self Closing and Centering Valve System.



    Typical applications

    The trap is typically applied to high temperature, medium-to-high pressure steam ducts and process equipments.

    Dimensions/Weight

    Flanged




    Size Dimensions (mm) Dimensions (in) Weight (kg) Weight (lb)
    L H1 H2 W1 W2 L H1 H2 W1 W2 JIS(FF) JIS(RF) ASME/JPI(RF) JIS(FF) JIS(RF) ASME/JPI(RF)
    10K,16K,20K 30K,40K 150lb,300lb 600lb 10K,16K,20K 30K,40K 150lb,300lb 600lb
    1/2” 250 75 95 30 195 9.8 3.0 3.7 1.2 7.7 12,7 14,0 12,7 14,0 28 30.9 28 30.9
    3/4” 13,5 14,2 13,5 14,2 29.8 31.3 29.8 31.3
    1” 14,0 15,2 14,0 15,2 30.9 33.5 30.9 33.5
    Size Dimensions (mm) Dimensions (in) Weight (kg) Weight (lb)
    L H1 H2 W1 W2 L H1 H2 W1 W2 ASME/JPI DIN JIS (FF) JIS (RF) ASME/JPI DIN JIS (FF) JIS (RF)
    150lb,300lb 600lb PN40 10K,16K,20K 30K,40K 150lb,300lb 600lb PN40 10K,16K,20K 30K,40K
    1/2" 250 75 95 30 195 9.8 3.0 3.7 1.2 7.7 12,7 14,0   12,7 14,0 28 30.9   28 30.9
    3/4" 13,5 14,2   13,5 14,2 29.8 31.3   29.8 31.3
    1" 14,0 15,2   14,0 15,2 30.9 33.5   20.9 33.5

    *Available flange standards: ASME/JPI, DIN, JIS
    *Customized face-to-face dimensions on request.
    *Please contact MIYAWAKI for further information.





    Socket Weld




    Size Dimensions (mm) Dimensions (in) Weight
    L H1 H2 W1 W2 L H1 H2 W1 W2 (kg) (lb)
    1/2” 220 75 95 30 195 8.7 3.0 3.7 1.2 7.7 11,5 25.4
    3/4” 11,6 25.6
    1” 11,7 25.8
    Model Connection

    Max. operating

    pressure

    Max. operating differential

    pressure

    Max. operating

    temperature

    Body

    material

    Type Size PMO(MPa) PMO(psig) ⊿PMX(MPa) ⊿PMX(psig) TMO(℃) TMO(℉)
    GTH12-5F Flanged
    FF,RF
    1/2” 3,2 464 0,5 73 400 752



    Cast

    steel

    SCPH2

    3/4”
    1”
    GTH12-16F 1/2” 1,6 230
    3/4”
    1”
    GTH12-25F 1/2” 2,5 363
    3/4”
    1”
    GTH12-32F 1/2” 3,2 464
    3/4”
    1”
    GTH12-45F 1/2” 5,0 725 4,5 652 425 800
    3/4”
    1”
    GTH12-5W

    Socket Weld

    SW

    1/2” 3,2 464 0,5 73 400 752
    3/4”
    1”
    GTH12-16W 1/2” 1,6 230
    3/4”
    1”
    GTH12-25W 1/2” 2,5 363
    3/4”
    1”
    GTH12-32W 1/2” 3,2 464
    3/4”
    1”
    GTH12-45W 1/2” 5,0 725 4,5 652 425 800
    3/4”
    1”

    ●Maximum allowable pressure (PMA): 3,2MPa (464psig) (GTH12-45: 5,0MPa (725psig))
    ●Maximum allowable temperature (TMA): 400℃ (752℉)  (GTH12-45: 425℃ (800℉))

    ●Minimum operating differential pressure (⊿PMN): 0,01MPa (1.5psig) ⊿PMN is the minimum operating differential pressure between the trap inlet and outlet.
    ●Maximum operating back pressure (PMOB): 90% of inlet-side pressure


    *Available flange standards: ASME/JPI, DIN, JIS
    *Customized size 1-1/4”, 1-1/2”, and 2” on request.
    *ASTM material (WCB) and Stainless Steel (SCS13A) on request.

    *Vertical installation on request.
    *A version with the direction of the inlet and outlet reversed on request.

    *Please contact MIYAWAKI for further information.


    ■ Additional products for reference
    Y strainer: YM1
    Air vent: AT9N
